Applications

These cables find application in a wide variety of industries ranging from nuclear and thermal power stations, defence, windmills, mining, marine & offshore applications, railways, cranes & reeling applications, lifts and other heavy duty equipment.

nuclear and thermal
power stations

defence

windmills

mining

Types & Sizes

• Single & multi core from 0.50 sq.mm to 630 sq. mm for voltage grade upto 3.3 kV (Unscreened)

Specification

9968 (Pt-1), IS 9857, BS: 6500, BS: 7919, BS EN: 60228, BS EN: 60332, IEC: 60502 and designed to meet customer’s requirements.

Key Features

• High performance in harsh conditions of heat and fire with better abrasion and weather resistance.

• Excellent resistant to oils, gasoline, and certain chemicals enhances the performance of this wire in
  extreme environments.

• Better flexibility and low bending radius.

• Wide range of operating temperature ranging from -55°C to 180°C.

• Customisation options available to meet customer’s needs.

Product Range

The railway segment needs complete connectivity across different divisions like

Conductor

Copper – Solid, Stranded (Circular) or Flexible – Bare or Tinned

Separator

Polyester tape, Fibre Glass Tape, or any other suitable material tape is applied over conductor

Inner Sheath

General purpose compound Type SE1/SE2, Heat resisting compound Type SE3/SE4/SE6 (HOFR), Silicon Rubber Type SE-5

Armour

Copper Wire/ Stainless Steel Braiding

Outer Sheath

General purpose compound Type SE1/SE2, Heat resisting compound Type SE3/SE4 /SE6 (HOFR), Silicon Rubber Type SE-5.

Insulation

General purpose compound Type IE1, Heat resisting compound Type IE2/IE3, Flame retardant compound Type IE4, Silicon Rubber Type IE 5. For identification of cores, coloured insulation/ numbered printing / numbered polyester tape / coloured proofed RC tape is used.
